Journal article
Coproduction of Syngas and Lime by Combined CaCO3-Calcination and CH4-Reforming Using a Particle-Flow Reactor Driven by Concentrated Solar Radiation
Energy & Fuels, Vol.23, pp.6207-6212
Dec/2009
Abstract
The combined CaCO3-calcination and CH4-reforming process is investigated using concentrated solar energy as the source of high-temperature process heal. The thermodynamic equilibrium composition indicates the coproduction of time and syngas (H-2/CO molar ratio = 1) at above 1200 K and I bar. Exploratory experimental runs were carried Out with a 5 kW solar chemical reactor comprised of a windowed cavity-receiver containing it flow of CH4 with suspended CaCO3 particles and directly exposed to high-flux solar radiation. At an optimal reactor configuration, CaCO3 and CH4 conversions or 83% and 38%, respectively, were achieved during 11 min of irradiation at a solar concentration ratio of 1884 suns and a normal temperature Of 1223 K. Effecting Simultaneously both reactions in a single solar-driven reactor eliminates CO2 emissions derived from the separate fossil-fuel-based production of these two energy-intensive material commodities.
Details
- Title
- Coproduction of Syngas and Lime by Combined CaCO3-Calcination and CH4-Reforming Using a Particle-Flow Reactor Driven by Concentrated Solar Radiation
- Creators
- V. Nikulshina (null)Martin M. Halmann (null) - 972WIS_INST___99A. Steinfeld (null)
- Resource Type
- Journal article
- Publication Details
- Energy & Fuels, Vol.23, pp.6207-6212; Dec/2009
- Number of pages
- 6
- Language
- English
- DOI
- https://doi.org/10.1021/ef9007246
- Record Identifier
- 993266054103596
